Laser marking machine is to use laser beam to mark permanently on the surface of various materials. The effect of marking is to expose the deep substances through the evaporation of the surface substances, so as to engrave exquisite patterns, trademarks and text.

1. Laser power: 100W/ 200W
2. Laser wavelength: 10.64um
3. Working area: 600mm×600mm
4. Marking speed: 0~12000mm/s
5. Laser type: RF Metal Tube Sealed Laser Source
6. Resetting positioning accuracy: 0.01mm
7. Laser energy control: 0-100% software setting

8. Minimum character: 0.4mm
9. Cooling system: Professional industrial forced water-cooling system
10. Power Supply: AC110V/ 220V±10%, 50Hz/60Hz
11. Control system: Chanxan dynamic control system
12. Support format:PHOTOSHOP,CORELDRAW,AUTOCAD,PLT,AI,BMP,DXF,SHX,TTF
13. Machine power: 1500W
14. Working platform: Honeycomb table

1. Large area engraving and dynamically marking on the surface of non-metal materials, such as decorative paper, wall paper, jeans, wood, leather, plastic, packaging material, glass, handiwork etc.
2. High precision marking with high speed and engraving depth controllable.
3. Perfect combination of surface marking and hollow-out carving in one process.
4. Easy to operate, work stable and efficient.
5. Approximate 5-8 years' working lifetime, and it could recycling utilize with gas inflation.

Sample- Decorative Paper Marking:

LASER MARKING MACHINE-ti.jpg

Packaging of Laser Marking Machine:
